Product Overview

SPA-C Cold Rolled Weathering Steel Coil & Sheet is a JIS G 3125 weathering steel supplied in annealed and skin-passed condition. It offers controlled atmospheric corrosion resistance, excellent dimensional accuracy, and smooth surface quality for architectural panels, precision stamping, and fabricated outdoor components.

09CuP corten steel

Technical Specifications

Item	Specification
Product Grade	SPA-C
Standard	JIS G 3125
Product Form	Cold Rolled Coil, Sheet, Slit Coil
Thickness	0.60-1.50 mm (custom available)
Width	600-1500 mm
Length	1000-6000 mm or customized
Delivery Condition	Annealed & Skin-passed
Edge Type	Mill Edge (ME), Slit Edge (SE)

Chemical Composition

Grade	C ≤	Si	Mn	P	S ≤	Cu	Cr	Ni ≤
SPA-C	0.12	0.25~0.75	0.20~0.50	0.070~0.150	0.040	0.25~0.60	0.30~1.25	0.65

Mechanical Properties

Grade	Elastic modulus	190 - 210 GPa at 20 °C
JIS G3125 Grade SPA-C	Elongation A5	26 % at 20 °C
	Poisson's ratio	0.3 [-] at 20 °C
	Tensile strength	450 MPa at 20 °C
	Yield strength	315 MPa at 20 °C

Typical Applications

Architectural façade panels

Curtain wall cladding systems

Decorative exterior wall panels

Precision stamped components

Outdoor signage systems

Landscape and garden structures

Processing Services

Slitting – Custom coil widths for downstream manufacturing.

Shearing – Precision sheet cutting with tight dimensional tolerance.

Laser Cutting – Profile cutting based on customer drawings.

Bending & Forming – Basic fabrication for structural or decorative parts.

Material Identification – Heat number marking and traceability upon request.

Quality Assurance

Inspection Process

Raw Material Chemical Composition Analysis (C, Si, Mn, P, S, Cu, Cr, Ni)
Spectrometer Chemical Verification
Thickness Measurement
Width & Length Dimensional Inspection
Flatness Inspection
Surface Appearance Inspection
Yield Strength Test
Tensile Strength Test
Elongation Test
Coil Weight Verification
Heat Number Traceability Verification
Mill Test Certificate (MTC) Review before Shipment

spa-c MTC

Certifications

Certification	Meaning
ISO 9001:2000	Quality Management System
ISO 14001:2004	Environmental Management System
Mill Test Certificate (EN 10204 3.1)	Certified material chemical and mechanical properties
JIS G 3125 Compliance	Compliance with Japanese weathering steel standard

Packaging & Shipping

Export Packing – Standard seaworthy export packing with steel straps, edge protectors, waterproof paper, and wooden pallets when required.

Rust Protection – Light oil coating or moisture-proof packaging available according to customer requirements.

Identification – Each coil marked with grade, heat number, size, weight, and production batch.

Loading Method – Container loading with steel supports and secure lashing to prevent movement during transport.

Shipping Method – FCL, LCL, bulk vessel, or air freight for samples.

China corten sheet Manufacturers

China plate corten steel Distributors

China weathering corten steel Suppliers

FAQ

Q: What is the difference between SPA-C and SPA-H?

A: SPA-C is cold rolled with thinner gauges (typically 0.6-1.5 mm), tighter tolerances, and a smoother surface. SPA-H is hot rolled, generally 1.6 mm and above, with a rougher mill-scale finish suitable for heavier structural applications.

Q: Can third-party inspection be arranged before shipment?

A: Yes. SGS, BV, TÜV, Intertek, or other customer-designated inspection agencies are accepted before shipment.

Q: What is the typical production lead time?

A: Delivery is usually completed within 7-45 days, depending on order quantity, specifications, and production schedule.

Q: Can I obtain a free sample before placing an order?

A: Yes. Free samples are available after price confirmation. Samples are normally prepared within 3-7 days and delivered by express in 3-5 days. Courier charges are paid by the customer.

Q: What international equivalent grades are comparable to SPA-C?

A: SPA-C is generally comparable to ASTM A606 Type 4, EN S355J2W / S355J2WP, and COR-TEN® B for reference. Final substitution should be confirmed according to project specifications.

Q: What are your payment terms?

A: For orders ≤ USD 1,000, 100% T/T in advance. For orders > USD 1,000, 30% T/T deposit with the 70% balance before shipment.
